2.7 Inch E-ink Touch Screen SPI Interface China 4 Grayscale E-ink Screen Manufacturer with Touch Panel

GDEY027T91-T01
This is a e-ink screen with capacitive touch screen, 2.7 inch, 264x176 resolution, SPI interface, and the display is capable to display images with black and white content.
1 Review(s) Sold:26
Have a question?
Price:
USD
$12.34
  • Product:
    EPD
    EPD with STM32 adapter board
    EPD with STM32 Demo Kit
    EPD with ESP32 adapter board
    EPD with ESP32 Demo Kit
    adapter board
Quantity:
-
+
(299 available)
Shipping Cost:
to
Estimated Delivery Time:
Please select the country you want to ship from
Please select the information you wantX
Inquiry Now
Add to Favorite Items
  • Description
  • Reviews(1)





Sleek 2.7-Inch E-Ink Touch Display with 4 Grayscale Levels









Introducing the 2.7-Inch E-Ink Touch Display – GDEW027T91-T01. This high-resolution, 264x176 pixel screen features a capacitive touch interface, perfect for interactive applications. With SPI connectivity, it supports multiple refresh modes: 3-second full refresh, 1.5-second fast refresh, and 0.42-second partial refresh. The standout feature is its exceptional power efficiency. Display an image and it holds indefinitely without power, making it ideal for solar or battery-powered devices. Perfect for any low-power project, this e-paper display combines touch functionality with ultra-low energy consumption.

Upgrade your applications with the 2.7-Inch E-Ink Touch Display and bring your innovative ideas to life with unmatched performance and efficiency.
















Special Features








Our product boasts distinctive features that set it apart from the competition









  ●  Effortless Interaction: Experience smooth, intuitive control with the advanced capacitive touch screen. Perfect for interactive signage, electronic shelf labels, and smart home devices, where adjustments are just a tap away. Elevate user experience and embrace innovation with every touch.
  ●  Infinite Display with Ultra-Low Power: Update once and display forever! Images stay vividly on screen even when unplugged, making it ideal for solar and battery-powered devices. Enjoy uninterrupted display with minimal energy consumption.
  ●  High Definition Clarity: Every pixel in crystal clear detail. With a 264x176 resolution, this display delivers stunning black-and-white imagery, meeting the highest standards for quality and clarity.
  ●  Seamless Integration: The standard SPI interface ensures versatile connectivity, effortlessly integrating with a range of microcontrollers and development boards. Enjoy endless possibilities for your projects.
  ●  Rugged Durability: Built to withstand tough environments, this display remains visible and reliable even after power-off. Perfect for outdoor use and challenging conditions.
  ●  Eco-Friendly Efficiency: Designed with the environment in mind, this display boasts low power consumption, reducing battery dependency and extending device life. Align your projects with eco-friendly initiatives and enjoy energy-efficient performance.












Technical Details









Please refer to the product drawings for detailed dimensions














Product Specifications









Please refer to the product specifications for more details








PART NUMBER GDEY027T91-T01 CONNECTOR 24 Pin FPC
SIZE 2.7 inch TYPE Dot Matrix
IC SSD1680 MAX GRAYSCALE 4
RESOLUTION 264x176 COLOR Black,White
OUTLINE SIZE(mm) 70.42x45.8x1.6 INTERFACE SPI
ACTIVE SIZE(mm) 57.29x38.19 FULL REFRESH(s) 3
PIXEL PITCH(mm) 0.217x0.217 FAST REFRESH(s) 1.5
OPERATING TEMP. 0℃~50℃ PARTIAL REFRESH TIME(s) 0.42
STORAGE TEMP. -25℃~70℃ POWER CONSUMPTION OF THE REFRESH(mW) 9
OPERATING VOLTAGE(V) 3.3 STANDBY POWER CONSUMPTION (mW) 0.003
TOUCH SCREEN CURRENT(mA) 5 TOUCH SCREEN INTERFACE IIC









Matching Driver Board
To facilitate the testing and comparison of e-paper, we recommend the following driver boards for you.
a. STM32-T01 (STM32 adapter Board) b. DESPI-L(T01) (STM32 Demo Kit) c. ESP32-T01 (ESP32 adapter Board) d. ESP32-L(T01) (ESP32 Demo Kit)











Files and Download

Click on the subheadings below to download

  ● GDEY027T91-T01 Specification ● GDEY027T91-T01_STM32 Sample Code
  ● TP027-S01 Touch Screen Drawing ● The latest Catalog of ePaper display
  ● Demo code for 2.7 inch touch panel FT6336 ● Disabling-Pop-Up-Blockers
  ● GDEY027T91-T01 (E-Paper+Touch Screen) Drawing
