1.54 inch 200x200 partial refresh e-paper display with frontlight with multifunction HAT connection adapter board GDEH0154D67-FL+DESPI-C03

GDEH0154D67-FL+DESPI-C03
1.54 inch e-paper display with frontlight, 200x200 resolution,  24 pins FPC connection, SPI interface, supports black and white, partial refresh, with DESPI-C03, multifunction HAT connection adapter board.
Price:
USD
$19.53
    Please select the information you wantX
Quantity:
-
+
(20 available)
  • Description
  • Size Chart
  • Measurement
  • Color Chart
  • Reviews

Any questions, just feel free to contact me, my email is: clara@good-display.com



General Description

This is a e-ink display module including a connector board and a 1.54 inch e-paper display with frontlight, 200x200 resolution, 24 pins FPC connection, optional FPC connector, communicating via SPI interface, with embedded controller(COG package) and on-chip stored waveform, supports black and white.



This connection board DESPI-C03 is aim to help users to learn how to use the E-paper Display easier. It not only has the interface for touch panel, but also has the power supply interface for frontlight. And the interface for touch panel supports SPI interface e-paper display and Parallel interface e-paper display.
The above price inclundes

1. 1.54 inch 200x200 e-paper display with frontlight GDEH0154D67-FL*1pc

2. Matched FPC Connector*1pc

3. FPC Connector for frontlight panel*1pc

4. Connector board DESPI-C03 *1pc

5. Helpful resources and manual(sent via email or download link) *1pc
If you only want to buy this e-paper display, click here:
http://upaj177.myueeshop.com/new-154-inch-e-paper-display-frontlight-partial-refresh-e-ink-gdeh0154d67-fl-p0266.html
Feature



· Support partial refresh, fast update and no flicker update.
· 200x200 resolution
· Come with helpful development resources and manual (STM32 platform )
· With front light
· The I2C signal master interface to read built-in temperature sensor.

· Development platform available STM32 / Arduino Raspberry Pi / ESP8266

Main Parameters

Part Number

GDEH0154D67-FL

Type

Dot Matrix

Resolution

200*200

Outline Size(mm)

31.8*37.32*1.8

Actve Size(mm)

27.00*27.00

Pixel Pitch(mm)

0.135*0.135

Operating Temp.

0~50C

Storage Temp.

—25~60C

Connector

24 Pin FPC, Pitch:0.5mm

Max Grayscale

2

Color

Black,White

Time of refresh(s) 2
Time of partial refresh(s) 0.26
Interface  SPI
Driving voltage 2.8V-3V
Power consumption of the e-paper only(mW) 4.95
Power consumption of the front-light(mW) 43.5


Part Number

DESPI-C03

Platform

STM32, Arduino, Raspberry Pi and so on

Function

Connection E-paper Display with DESPI-M02

Outside Dimension

52x36mm

Interface

USB Interface

Power Input

DC3.3V

Feature

Fully and Partial refresh

Operating Temp

-20~70℃

Specification download
